AirTAC氣動手指-HFY系列
-
商品資訊
|
缸徑(mm) |
HFY6 |
HFY10 |
HFY16 |
HFY20 |
HFY25 |
HFY32 |
|
動作型式 |
復動型 / 單動常開型 |
|
工作介質 |
空氣(經40μm以上濾網過濾) |
|
使用壓力範圍 |
復動型 |
0.2~0.7MPa(29~100psi)(2.0~7.0bar) |
0.15~0.7MPa(22~100psi)(1.5~7.0bar) |
|
單動型 |
0.3~0.7MPa(45~100psi)(3.0~7.0bar) |
0.25~0.7MPa(36~100psi)(2.5~7.0bar) |
|
工作溫度℃ |
-20~70 |
|
給油 |
氣缸：不需要 夾爪：潤滑脂 |
|
緩衝型式 |
防撞墊 |
|
最高使用頻率 |
180(c.p.m) |
|
安裝方式 |
側面安裝 / 正面螺紋孔安裝 / 正面通孔安裝 / 尾部安裝 |
|
接管口徑 |
M3*0.5 |
M5*0.8 |
|
所配傳感器 |
CMSH / DMSH / EMSH |
CMSG / DMSG / EMSG |
|
型號/符號 |
A |
AB |
B |
C |
CA |
D |
DA |
E |
EA |
EB |
F |
FA |
K |
KA |
KB |
KC |
L |
|
HFY6 |
47.5 |
36 |
10.5 |
20 |
14 |
4 |
4 |
M2*0.4 |
2.5 |
5 |
11 |
12 |
M3*0.5 |
全牙 |
12 |
26 |
– |
|
HFY10 |
52.5 |
38.5 |
16.5 |
23 |
14 |
6.4 |
4 |
M2.5*0.45 |
3 |
5.7 |
12 |
14.5 |
M3*0.5 |
5 |
16 |
23 |
M3*0.5 |
|
HFY16 |
62.5 |
44.5 |
23.5 |
30.5 |
24 |
8 |
7 |
M3*0.5 |
4 |
7 |
16 |
19 |
M4*0.7 |
7 |
24 |
24.5 |
M4*0.7 |
|
HFY20 |
78 |
55 |
27.5 |
42 |
30 |
10 |
8 |
M4*0.7 |
5 |
9 |
20 |
23.5 |
M5*0.8 |
8 |
30 |
29 |
M5*0.8 |
|
HFY25 |
92 |
60.5 |
33.5 |
52 |
36 |
12 |
10 |
M5*0.8 |
8 |
12 |
27 |
33 |
M6*1.0 |
10 |
36 |
30 |
M6*1.0 |
|
HFY32 |
96.5 |
68 |
40 |
60 |
42 |
18 |
10 |
M6*1.0 |
6 |
14 |
27 |
29.5 |
M6*1.0 |
10 |
44 |
37.5 |
M6*1.0 |
|
型號/符號 |
LA |
LB |
LC |
M |
MA |
MB |
MC |
N |
NA |
P |
PA |
PB |
UA(張開) |
UB(閉合) |
|
HFY6 |
– |
– |
– |
– |
– |
– |
– |
70+0.05 |
1.5 |
M3*0.5 |
19 |
1.5 |
30° |
10° |
|
HFY10 |
6 |
18 |
12 |
M3*0.5 |
6 |
11.5 |
27 |
110+0.05 |
1.5 |
M3*0.5 |
19 |
10 |
30° |
10° |
|
HFY16 |
8 |
22 |
15 |
M4*0.7 |
8 |
16 |
30 |
170+0.05 |
1.5 |
M5*0.8 |
18.5 |
13 |
30° |
10° |
|
HFY20 |
10 |
32 |
18 |
M5*0.8 |
10 |
18.5 |
35 |
210+0.05 |
1.5 |
M5*0.8 |
22 |
15 |
30° |
10° |
|
HFY25 |
12 |
40 |
22 |
M6*1.0 |
10 |
22 |
36.5 |
260+0.05 |
1.5 |
M5*0.8 |
23.5 |
20 |
30° |
10° |
|
HFY32 |
12 |
46 |
26 |
M6*1.0 |
10 |
26 |
30 |
340+0.05 |
2 |
M5*0.8 |
31 |
24 |
30° |
10° |
-
